The BMR Tower Pair

The BMR Tower Pair

Regular price $4,200.00
Regular price Sale price $4,200.00
Sale Sold out
Material

Low stock

Although our BMR monitor provides exemplary bass extension down to 34 Hz, true full range performance requires a larger cabinet and a larger woofer.  Working with Paul Kittinger, who is an expert in transmission line design, we have developed a mass-loaded transmission line cabinet that utilizes the same 8-inch Scan Speak Revelator woofer that performed so well in the Philharmonic Model 3.

In our opinion, the Revelator woofer is the finest available in this size class and provides flat in-room response to 25 Hz with absolutely no port noise.  Useful response extends to 20 Hz, which you can test for yourself using our demonstration tracks

In addition, the use of two BMR midrange units in an MTM configuration improves power handling and provides increased clarity in the lower treble and upper midrange.

Click here for full measurements of the BMR Tower.

Specifications

Cabinet Mirror Ebony, Mirror Rosewood, or Satin Walnut
Tweeter RAAL 64-10X OEM
Midrange Balanced Mode Radiator 2.5"
Woofer ScanSpeak Revelator 8"
Frequency Response   25 Hz - 20kHz (+ 1.5 / - 3db) Anechoic
Sensitivity 86 dB (2.83v/1M)
Box Alignment Mass Loaded Transmission Line
Dimensions 44" H x 12" W x 15-1/2" D
Weight 72 lbs
Impedance 6 Ohms
Crossover Linkwitz-Riley 2nd Order Acoustic at 850 Hz,
Linkwitz-Riley 4th Order Acoustic at 3,800 Hz
